SignaRoad®

SIGNAROAD

FEATURES & BENEFITS INCLUDE

Environmentally Friendly

SignaRoad construction mats will not absorb or retain harmful chemicals or invasive species and thus will not transfer contaminants to other job sites.

Maximum Shipping Efficiency

Up to 500 DuraDeck mats can be transported on a standard tractor trailer or ocean shipping container, and the 4 ft. x 8 ft. mats fit inside the bed of most pickup trucks.

Inventory Tracking

All mats have unique serial numbers for inventory control and tracking. RFID chips are incorporated into the core of every mat during the manufacturing process.

Surface Preparation

SignaRoad can be installed with little to no ground preparation over grass, gravel, sand, soil, concrete, asphalt, ice, snow, mud and other surfaces.

Weight-Bearing Capacity

SignaRoad has a weight-bearing capacity of up to 400 psi / 57,600 lbs. per sq. ft.

Non-Conductive

SignaRoad composite materials are inert, providing a non-conductive safe working platform.

SignaRoad® is the Most Versatile Medium-duty
Composite Mat in the Industry

SignaRoad^® is designed to create a medium-duty temporary roadway or pedestrian accessway quickly and easily. From temporary roadways for remote utility repair projects to pedestrian accessways for concerts and music festivals, SignaRoad provides superior temporary access and ground protection for almost any vehicle, with advanced design features and an easy-to-use connection system.

Actual Size	6.8′ (L) x 10′ (W) x 2.5″ 2 m (L) x 3 m (W) x 6.4 cm
Usable Platform	6′ (L) x 9.3′ (W) x 2.5″ 1.9 m (L) x 2.8 m (W) x 6.4 cm
Usable Roadway	6′ (L) x 10′ (W) x 2.5″ 1.9 m (L) x 3 m (W) x 6.4 cm
Weight	496 lbs. (225 kg)
Weight Load	400 lbs. sq./in.
Shipping Info	90 mats per standard 40′ shipping container or 53′ truck
